16：9 ZEUS Series / Ultra-Quiet Motorized Projection Screen
🔌Power Cord Location: Right side when facing the screen.
⏹︎ Dimensions & Installation
Industry-exclusive 6-year motor warranty
Curved housing finished with white piano-gloss coating for a premium appearance
Sliding rail or fixed bracket mounting design for easy wall or ceiling installation
Built-in automatic stop system with adjustable upper and lower limit positions
Hidden accessory design keeps connectors and assembly screws concealed for a clean, elegant finish
One-piece hydraulic-formed weighted bar maintains excellent screen flatness without deformation
Optional IR infrared remote control available for office automation and smart home integration
Matte white screen material available with four-side or left/right black borders.Fiberglass or synthetic woven backing with blackout rear coating for enhanced image performance
| Size | Model No. |
Viewing Area W x H (cm) |
Overall Screen Dimensions (Incl. Borders) W x H (Incl. 4cm Borders & 90cm Top Drop) |
Product Dimensions (Incl. Brackets) W x D x H cm |
Top Drop |
|---|---|---|---|---|---|
| Case Series: BS (Zeus) | |||||
| 80” | BZ-80HD | 177.1 x 99.6 | 185.1 x 193.6 |
202.7 x 13.4 x 15.7
|
90 |
| 90” | BZ-90HD | 199.2 x 112.1 | 207.2 x 206.1 |
224.8 x 13.4 x 15.7
|
90 |
| 100” | BZ-100HD | 221.4 x 124.5 | 229.4 x 218.5 | 247 x 13.4 x 15.7 | 90 |
| 110” | BZ-110HD | 243.5 x 137 | 251.5 x 231 |
269.1 x 13.4 x 15.7
|
90 |
| 120” | BZ-120HD | 265.7 x 149.4 | 273.7 x 243.4 |
291.3 x 13.4 x 15.7
|
90 |
