16:9 CUPID Series / Fast Foldable Projection Screen

Inspired by the precision and speed of Cupid’s strategy — designed for rapid deployment and maximum efficiency.
The large-format screen features a quick-folding structure for effortless storage and ultra-fast setup, delivering professional presentation performance anytime, anywhere.

Download

Share：

Product Introduction
Product Specifications

CUPID-20

⏹︎ Dimensions & Installation

Exclusive locking mechanism design with a completely flush button structure, eliminating protruding parts commonly found in traditional folding screens.

Constructed with high-strength 32×32 mm or 32×64 mm aluminum alloy folding frames, combined with intelligent structural engineering and military-grade shockproof flight cases.

Decorative trims are specially treated to effectively reduce glare and reflection.

Black border material is made from highly flexible PVC, engineered with a frameless edge design. Regardless of the screen size, the black border can be folded into an extremely compact form for easy storage and transportation, while remaining resistant to temperature and humidity changes.

Size	Model	Viewing Area (W × H) mm	Aluminum Frame	Black Border Width (mm)	H1 Size (mm) MAX		H1 Size (mm) MIN		Packing Size	Gross Weight
Size	Model	Viewing Area (W × H) mm	Aluminum Frame	Black Border Width (mm)	MAX	MIN	MAX	MIN	Packing Size	Gross Weight
100”	CUN-100	2212 x 1245	30.5x30.5	65	884	284	2266	1666	117x33x31	19kg
120”	CUN-120	2655 x 1494	30.5x30.5	65	1589	239	3211	1861	117x33x31	21kg
150”	CUN-150	3319 x 1867	32x32	75	1848	198	3870	2220	117x33x31	23kg
180”	CUN-180	3982 x 2240	32x32	90	1658	158	4059	2559	118x41x40	43kg
200”	CUN-200	4425 x 2489	32x32	90	1157	257	3794	2894	160x43x40	47kg
250”	CUN-250	5531 x 3112	63x32	100	1142	292	4486	3636	167x56x54	72kg
300”	CUN-300	6637 x 3734	63x32	100	1109	209	5061	4161	167x56x54	79kg
350”	CUN-350	7743 x 4356	63x32	100	1767	717	6351	5301	185x61x60	120kg
